All Vessels AHTS A802 A802 Anchor Handling Tug Supply
Download Full Spec Sheet
With 80-ton bollard pull, DP2 and a clear deck space of 435 m2, the A802 is ideally sized to tow the latest jack-up drilling rig. The propeller diameter is optimised for continuous 80-ton bollard pull with 6,000 bhp, produced by fuel-efficient, medium-speed engines.
The A802 has a wealth of deck space and accommodation available, opening it up to other options such as ROV support and oil recovery. The A802 is both SPS 2008 and MLC 2006 compliant.
A802 Specs
- Length Overall
- 65m
- Breadth Moulded
- 16m
- Depth Moulded
- 6.2m
- Draft (max)
- 5.2m
- GRT
- Approx 1,600T
- Class
- ABS
- Notation
- ✠A1 Towing Vessel, Anchor Handling Vessel, Fire Fighting Class 1, Offshore Support Vessel, Ⓔ ✠ AMS, ✠DPS-2, OSR-C1, SPS
- Horsepower
- 6000 BHP
- Bollard Pull
- ≥ 80T
- Stern Thruster
- 1 x 8T thrust CPP
- Bow Thrusters
- 2 x 10T thrust CPP
- Dynamic Positioning
- DPS - 2
- Accommodation
- 50 men
